Description
*CLEARANCE!* OKI Executive Series ES7470dnMFP 4-in-1 Color Laser MFP Printer+FAX+Duplexer 36PPM (RRP$2498)
(P/N:45376113)
Overview
A robust, all-in-one A4 colour multifunction printer, the ES7470/MC770 combines OKI XP (smart Extendable Platform) open platform architecture with high-performance print, copy, scan and fax functions, providing efficient document management and maximizing productivity.
Specifications
-
Type Floor / Desktop
Scanning Method Color CIS
Printing Technology Digital 4 LED Full-color Electrophotographic Printing Technology
Copy Density Adjustment 11 levels (Manual)
Input Capacity Tray 1 : 580 sheets
(Optional)Additional Tray : 580 sheets
(Optional)Large Capacity Feeder : 2400 sheets
Multi-purpose tray : 110 sheets
Scan Resolution Up to 600 x 600 dpi
Print Resolution Up to 600 x 600 dpi
Original Type Sheet, Book
Original Size Flatbed: A4, A5, Letter, Legal 14; ADF: A4, A5, Letter, Legal 14
Copy Paper Size *1 A4, A5, A6, B5, Letter, Legal 13, Legal 13.5, Legal 14, Executive
Reduction / Enlargement 25 400 %
Maximum Copies 999 sheets
Copy Speed A4 40 cpm color, 40 cpm mono
First Copy Out Time Color: Approx. 13.0 seconds, Mono: Approx. 13.0 seconds
Warm-up Time Approx. 60.0 seconds from power-on
Approx. 35.0 seconds from power save
Power Source Single phase 220 - 240 VAC ±10%, 50/60 Hz ±2%
Power Consumption Operating: Max. 1,500W / Ave. 800W
Idle: 130W
Power Save: 60.0W
Deep Sleep: 2.0W
Auto-Off: 0.5W
Memory (Std./Max.) 2GB/2GB
Safety & Environment Regulation Energy Star, GS Mark, EMC-Directive, CE Mark
Noise Level Operating :Approx. 57 dBA
Idle: < 37 dBA
Power save: Background level
Operating Environment Operating: 10 - 32 °C, 20 - 80 %RH
Storage: 0 - 43 °C, 10 - 90 %RH
Dimensions(WxDxH) 552 x 604 x 675 mm
Weight(includes supplies) Approx. 50.0 kg
Duty Cycle Recommended: 4,000 pages/month
Maximum: 60,000 pages/month
In the Box Manuals, Starter toner cartridge x 4, Image Drum x 4, Power cable, Staple Cartridge, DVD-ROM, Telephone Cable
Print
Print Speed A4 34 ppm color, 36 ppm mono
First Print Out Time Color: Approx. 9.0 seconds
Mono: Approx. 8.0 seconds
Print Resolution 600 x 600 dpi
600 x 600 dpi (32 levels)
600 x 1200 dpi (2 levels)
Physical dot pitch: 600 dpi
Interface 1000BASE-T/100BASE-TX/10BASE-T, USB 2.0 (High Speed), (Optional) Wireless LAN (IEEE802.11b/g/n), USB 2.0 (High Speed) Host
Protocol TCP/IP, IPX/SPX, EtherTalk
Printer Language Postscript/PDF Emulation, PCL 6 (XL) emulation, XPS emulation, PCL 5c emulation, PCL 5e emulation
Supported OS (Click here for latest OS) Windows 8.1, Windows 8.1 x64, Windows 8, Windows 8 x64, Windows 7, Windows 7 x64, Windows Vista, Windows Vista x64, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2, Windows Server 2008, Windows Server 2008 x64, Windows Server 2003, Windows Server 2003 x64, OS X 10.10, OS X 10.9, OS X 10.8, OS X 10.7, Mac OS X 10.6, Mac OS X 10.5, Mac OS X 10.4
Memory (Std./Max.) 2GB/2GB
Hard Disk Drive 320 GB
Font PostScript emulation 136 fonts, PCL emulation 80 scalable fonts
Paper Size A4, A5, A6, B5, Letter, Legal 13, Legal 13.5, Legal 14, Executive, Envelopes, Postcard, Index Card (3" x 5") (75 x 125mm), Custom Size: Width 64-216 mm x Length 127-1321 mm
Paper Weight Tray 1 : 64 - 220 gsm
(Optional)Additional Tray : 64 - 220 gsm
(Optional)Large Capacity Feeder : 64 - 220 gsm
Multi-purpose tray : 64 - 250 gsm
Input Capacity Tray 1 : 580 sheets
(Optional)Additional Tray : 580 sheets
(Optional)Large Capacity Feeder : 2400 sheets
Multi-purpose tray : 110 sheets
Output Capacity Face Down : Max. 500 sheets
Face Up : Max. 100 sheets
Finishing Function Offline stapling 20 sheets
Scan
Scan Resolution Max. 600 x 600 dpi
Scan Speed Max. 40 ipm Color, 40 ipm mono
Interfaces 1000BASE-T/100BASE-TX/10BASE-T, USB 2.0 (High Speed) Host, USB 2.0 (High Speed)
Supported Protocol SMB, FTP(S), TWAIN, WIA2.0, ICA
Output Format Secure PDF, High compression PDF, JPEG, TIFF, XPS
Driver TWAIN, WIA2.0(Windows Vista or later)
Fax
Applicable Line PSTN, PBX
Interface RJ-11 x 2 (Line, Tel)
Transmission Resolution Normal: 8 dots/mm x 3.85 lines/mm
Fine/Photo: 8 dots/mm x 7.7 lines/mm
Ultra-Fine: 16 dots/mm x 15.4 lines/mm
Communication Speed Super G3: 33.6kbps
Encoding Method MH, MR, MMR, JBIG
Communication Mode ITU-TG3, Super G3
Transmission Original Size Max. Legal 14, Length 356 mm
Paper Size Max.Legal 14, Min.A5
Transmission Time Approx. 3.0 sec. / page
Memory Max. 1,000 pages (1000MB)
Other Function Broadcast(200 group, 400 locations/group), Delayed Tx, PC Fax, Speed Dial(3000 locations)
Document feeder
Type Reverse Automatic Document Feeder (RADF)
Original Size A4, A5, A6, B5, Letter, Legal 13, Legal 13.5, Legal 14, Executive
Original Weight 60 - 105 gsm
Capacity Max. 100 sheets
Original Exchange Speed Simplex 40 ppm color, 40 ppm mono
