Description

Zebra ZT231T 4-Inch Industrial Thermal Transfer Label Printer with Cutter [ZT23142-T2P000FZ] is a versatile 203dpi industrial barcode printer designed for warehousing, logistics, manufacturing, inventory management and product identification.
Featuring a factory-configured automatic cutter with catch tray, the Zebra ZT231T can print and cut labels for convenient collection and handling. With print speeds of up to 305mm per second (12 ips), a 4.3-inch colour touchscreen and built-in USB, Serial and Ethernet interfaces, it provides a productive solution for demanding business labelling workflows.
- Zebra ZT231 Industrial Barcode Label Printer
- Manufacturer Part Number: ZT23142-T2P000FZ
- Integrated Cutter with Catch Tray Included
- Thermal Transfer and Direct Thermal Printing
- 203dpi Print Resolution
- Maximum Print Speed: 305mm/sec (12 ips)
- Maximum Print Width: 104mm (4.09 inches)
- 4.3-inch Full-Colour Resistive Touchscreen
- USB 2.0, USB Host, RS-232 Serial and Ethernet 10/100
- Bluetooth Low Energy (BTLE) for Supported Configuration Functions
- Supports Thermal Transfer Ribbons up to 450m
- Durable Metal Frame with Side-Loading Media Design
- Ideal for Warehouse, Logistics, Manufacturing and Barcode Labels
Technical Specifications
| Brand | Zebra |
| Series | ZT231 |
| Manufacturer Part Number | ZT23142-T2P000FZ |
| Printer Category | Industrial Barcode Label Printer |
| Print Methods | Thermal Transfer / Direct Thermal |
| Print Resolution | 203dpi / 8 dots per mm |
| Maximum Print Speed | 305mm/sec / 12 ips |
| Maximum Print Width | 104mm / 4.09 inches |
| Maximum Print Length | 3988mm at 203dpi |
| Supported Media Width | 19.4mm to 114mm |
| Minimum Label Length in Cutter Mode | 25mm |
| Media Types | Continuous, Die-Cut, Notched and Black-Mark Media |
| Maximum Media Roll Diameter | 203mm with 76mm Core |
| Ribbon Capacity | Up to 450m |
| Ribbon Width | 51mm to 110mm |
| Ribbon Core | 25.4mm / 1 inch |
| Display | 4.3-inch Colour Resistive Touchscreen |
| Connectivity | USB 2.0, USB Host, RS-232 Serial, Ethernet 10/100 |
| Bluetooth | Bluetooth Low Energy (BTLE) |
| Built-in Wi-Fi | No – Optional Upgrade |
| Printer Languages | ZPL, ZPL II, EPL, EPL2 |
| Memory | 256MB SDRAM / 256MB Flash |
| Media Sensors | Movable Transmissive and Reflective Sensors |
| Automatic Cutter | Yes – Included |
| Catch Tray | Yes – Included |
| Peeler / Dispenser | Not Included |
| Base Printer Dimensions | 432 x 241 x 324mm (L x W x H) |
| Base Printer Net Weight | Approx. 9.1kg, Excluding Configuration-Specific Accessories |
Note: The cutter and catch tray may affect the overall installed dimensions and weight. Base printer specifications are provided for reference.
Automatic Cutter with Catch Tray Included
Unlike standard Zebra ZT231 tear-off configurations, this model is supplied with an integrated cutter and catch tray.
- Automatically cuts compatible label media after printing
- Supports efficient batch label production
- Catch tray collects cut labels for convenient retrieval
- Reduces manual tearing during supported printing workflows
- Ideal for product labels, identification tags and continuous media applications
Important: Cutter compatibility depends on the label material, thickness and application. Use cutter-approved media and avoid cutting directly through adhesive areas unless supported by the media specification.
Fast 203dpi Industrial Barcode Printing
The Zebra ZT231 203dpi model offers print speeds of up to 305mm per second, making it suitable for high-volume commercial labelling.
- Warehouse inventory and shelf labels
- Shipping and dispatch labels
- Carton and pallet identification
- Product and packaging labels
- Manufacturing work-in-progress labels
- Barcode and QR code labels
- Asset and equipment identification
Thermal Transfer and Direct Thermal Printing
This ZT231T supports two printing technologies:
- Thermal Transfer: Uses compatible ribbon and label media to create durable printed labels suitable for longer-term applications.
- Direct Thermal: Uses compatible heat-sensitive media without a ribbon, ideal for shipping and short-term labels.
For thermal transfer printing, select the correct ribbon formulation and label material according to the required durability and operating environment.
Up to 450m Thermal Transfer Ribbon Capacity
Long ribbon capacity helps minimise interruptions in busy warehouse and manufacturing environments.
- Maximum Ribbon Length: 450m
- Ribbon Width: 51mm to 110mm
- Ribbon Core: 25.4mm
- Compatible with selected wax, wax/resin and resin ribbon formulations, depending on media
Flexible Connectivity and Business Integration
- USB 2.0: Direct computer connectivity
- USB Host: Supported USB peripherals
- RS-232 Serial: Integration with compatible legacy systems
- Ethernet 10/100: Wired network label printing
- Bluetooth Low Energy: Supported setup and printer management
Bluetooth Low Energy is not equivalent to standard Bluetooth wireless label printing. Wi-Fi is not built into this configuration.
Zebra ZT231 Model Comparison
| Model | Print Method | Resolution | Cutter |
|---|---|---|---|
| ZT23142-T2P000FZ | TT / DT | 203dpi | Included with Catch Tray |
| ZT23142-T0P000FZ | TT / DT | 203dpi | Not Included |
| ZT23143-T0P000FZ | TT / DT | 300dpi | Not Included |
| ZT23142-D0P000FZ | DT Only | 203dpi | Not Included |
What's Included?
- 1 x Zebra ZT231 203dpi Thermal Transfer Industrial Label Printer
- 1 x Integrated Cutter Assembly
- 1 x Catch Tray
- Applicable Power Cord
- Manufacturer Documentation
Note: Label rolls and thermal transfer ribbons are not included unless explicitly stated. A peeler, rewinder and Wi-Fi module are not included in this configuration.
Frequently Asked Questions (FAQ)
Does ZT23142-T2P000FZ include a cutter?
Yes. This configuration includes an automatic cutter and catch tray.
What is the printing resolution?
203dpi, suitable for standard barcode, shipping, warehouse and product labels.
How fast does it print?
Up to 305mm per second (12 inches per second), depending on media and print settings.
Can this model print without a ribbon?
Yes. In Direct Thermal mode, it prints on compatible heat-sensitive labels without a ribbon. Thermal Transfer mode requires a compatible ribbon.
Does it have Ethernet?
Yes. It includes built-in 10/100 Ethernet, USB 2.0, USB Host and RS-232 Serial interfaces.
Can I print over Bluetooth?
Bluetooth Low Energy is provided for supported configuration and management functions. Conventional Bluetooth wireless printing should not be assumed.
Is the cutter suitable for all label materials?
No. Label media must meet Zebra's cutter compatibility requirements, including suitable material thickness and cutting characteristics.
Applications:
- Batch production label printing
- Manufacturing and product identification
- Shipping and logistics labels
- Inventory and asset tagging
Why Choose This Product:
- Durable, long-lasting label output via thermal transfer technology
- Built-in cutter ensures clean separation for improved workflow
- Multiple connectivity options for easy system integration
- Proven Zebra reliability for industrial environments
Customer Reviews:
★★★★★ “The cutter with tray saves us so much time on our production line.” – Manufacturing Manager
★★★★★ “Excellent quality, prints stay readable even in harsh conditions.” – Warehouse Supervisor
