Description

Zebra ZT231D 4-Inch Industrial Direct Thermal Label Printer 203dpi [ZT23142-D0P000FZ] is a high-performance industrial barcode printer designed for warehouses, logistics operations, manufacturing facilities and distribution centres.
Featuring fast printing speeds of up to 305mm per second (12 inches per second), a durable metal frame, a 4.3-inch colour touchscreen and built-in USB, Serial and Ethernet connectivity, the Zebra ZT231D provides a reliable solution for high-volume barcode and shipping label printing.
This model uses Direct Thermal printing technology, eliminating the need for toner, ink or thermal transfer ribbons.
- Zebra ZT231 Series Industrial Barcode Label Printer
- Manufacturer Part Number: ZT23142-D0P000FZ
- Direct Thermal (DT) Printing – No Ribbon Required
- 203dpi Print Resolution
- Maximum Print Speed: 305mm/sec (12 ips)
- Maximum Print Width: 104mm (4.09")
- 4.3" Full-Colour Resistive Touchscreen
- USB 2.0, USB Host, RS-232 Serial and 10/100 Ethernet
- Bluetooth Low Energy (BTLE) for Supported Setup and Management Functions
- Durable Metal Frame and Industrial Construction
- Supports ZPL, ZPL II, EPL and EPL2 Printer Languages
- Standard Tear-Off Configuration
- Ideal for Shipping, Warehouse, Inventory and Barcode Labels
Technical Specifications
| Brand | Zebra |
| Series | ZT231 |
| Model | ZT231D |
| MPN | ZT23142-D0P000FZ |
| Printer Category | Industrial Barcode Label Printer |
| Print Method | Direct Thermal |
| Print Resolution | 203dpi / 8 dots per mm |
| Maximum Print Speed | 305mm/sec (12 ips) |
| Maximum Print Width | 104mm / 4.09" |
| Maximum Print Length | 3988mm / 157" |
| Media Width | 19.4mm – 114mm |
| Maximum Roll Diameter | 203mm with 76mm Core |
| Display | 4.3" Colour Resistive Touchscreen |
| Connectivity | USB 2.0, USB Host, RS-232 Serial, Ethernet 10/100 |
| Bluetooth | Bluetooth Low Energy (BTLE) |
| Built-in Wi-Fi | No – Optional Upgrade Available |
| Printer Languages | ZPL, ZPL II, EPL, EPL2 |
| Memory | 256MB SDRAM / 256MB Flash |
| Media Sensors | Adjustable Transmissive and Reflective |
| Media Output | Standard Tear-Off |
| Cutter / Peeler | Not Included |
| Printer Dimensions | 432 x 241 x 279mm (L x W x H) |
| Printer Net Weight | Approx. 9.1kg |
High-Speed 203dpi Industrial Label Printing
The Zebra ZT231D is designed for businesses requiring fast, reliable printing of standard barcode and shipping labels.
With a maximum speed of 305mm per second, the 203dpi model delivers higher throughput than the 300dpi version, making it particularly suitable for high-volume dispatch and warehouse environments.
- Shipping and courier labels
- Warehouse inventory labels
- Product identification and SKU labels
- Carton and pallet identification
- Receiving and dispatch labels
- Retail and logistics barcode labels
- Manufacturing work-in-progress labels
Direct Thermal Printing – No Ribbon Required
The ZT23142-D0P000FZ uses Direct Thermal technology, applying heat directly to compatible heat-sensitive label media.
- No toner or ink cartridges required
- No thermal transfer ribbons required
- Convenient label roll replacement
- Reduced consumable complexity
- Ideal for shipping and short-to-medium-life labels
Important: Direct thermal labels may fade with prolonged exposure to heat, sunlight or chemicals. For applications requiring long-lasting labels, consider a Zebra Thermal Transfer model.
Built for Warehouse and Logistics Environments
The Zebra ZT231 features a durable industrial design with a metal frame and convenient side-loading media path.
- Robust construction for demanding commercial environments
- Large clear media viewing window
- 4.3-inch colour touchscreen for printer configuration
- Supports Zebra Print DNA software tools
- Suitable for integration with compatible warehouse and shipping systems
Flexible Wired Connectivity
The ZT23142-D0P000FZ provides multiple standard interfaces for connecting to business systems.
- USB 2.0: Direct computer connection
- Ethernet 10/100: Wired network label printing
- RS-232 Serial: Compatible legacy equipment integration
- USB Host: Supported peripherals and storage devices
- Bluetooth Low Energy: Supported setup and management functions
Wi-Fi is not included as standard. Bluetooth Low Energy should not be confused with conventional Bluetooth wireless printing.
Zebra ZT231 203dpi vs 300dpi Direct Thermal
| Feature | ZT231 203dpi DT | ZT231 300dpi DT |
|---|---|---|
| Part Number | ZT23142-D0P000FZ | ZT23143-D0P000FZ |
| Print Resolution | 203dpi | 300dpi |
| Maximum Print Speed | 305mm/sec (12 ips) | 203mm/sec (8 ips) |
| Maximum Print Width | 104mm | 104mm |
| Best Application | Fast Shipping and Barcode Labels | Fine Text and Detailed Barcodes |
Direct Thermal vs Thermal Transfer
The Zebra ZT231 range includes both Direct Thermal and Thermal Transfer models. Choosing the correct printing method is important for label durability and consumable compatibility.
- Direct Thermal: Uses heat-sensitive labels without a ribbon. Ideal for shipping, dispatch and temporary labels.
- Thermal Transfer: Uses a compatible ribbon and label material. Better suited to durable asset, product and long-life labels.
Related Zebra ZT231 Printers
- Zebra ZT231 300dpi Direct Thermal – Higher-resolution alternative
- Zebra ZT231 203dpi Thermal Transfer – Ribbon-based industrial printing
- Zebra ZT231 300dpi Thermal Transfer – Fine-detail durable labels
- Zebra ZT231 203dpi Thermal Transfer with Cutter – Automatic label cutting
What's Included?
- 1 x Zebra ZT231 203dpi Direct Thermal Industrial Label Printer
- Manufacturer Part Number: ZT23142-D0P000FZ
- Applicable Power Cable
- Manufacturer Documentation
Note: Thermal label rolls, optional cutter, peeler and Wi-Fi accessories are not included unless specifically stated.
Frequently Asked Questions (FAQ)
Is the Zebra ZT23142-D0P000FZ Direct Thermal?
Yes. This is a 203dpi Direct Thermal model that prints on compatible heat-sensitive label media without a ribbon.
How fast does the Zebra ZT231 203dpi print?
It supports speeds of up to 305mm per second, equivalent to 12 inches per second.
Does this printer support Ethernet?
Yes. It includes built-in 10/100 Ethernet, USB 2.0, USB Host and RS-232 Serial connectivity.
Does the ZT231 support Bluetooth printing?
This configuration includes Bluetooth Low Energy for supported setup and management functions. Standard Bluetooth wireless label printing is not guaranteed.
Does the printer require a ribbon?
No. The ZT23142-D0P000FZ is a Direct Thermal printer and does not require thermal transfer ribbons.
Does this printer include a cutter or peeler?
No. This configuration is supplied with standard tear-off media handling.
Is 203dpi or 300dpi better for shipping labels?
203dpi is generally suitable for standard shipping labels and offers faster maximum printing speed. Choose 300dpi for finer text and more detailed barcodes.
